| NO | Dimension | NO | Dimension | NO | Dimension |
|---|---|---|---|---|---|
| 1 | Φ40X70(8) | 21 | Φ70X110(4P) | 41 | Φ100X110(45X15) |
| 2 | Φ45X80(35X12) | 22 | Φ70X110(45X15) | 42 | Φ100X140(45X22) |
| 3 | Φ45X80(10) | 23 | Φ70X140(45X22) | 43 | Φ110X140(45X22) |
| 4 | Φ50X80(10) | 24 | Φ75X110(35X12) | 44 | Φ110X160(70X3P) |
| 5 | Φ50X80(35X12) | 25 | Φ75X110(45X15) | 45 | Φ115X140(45X22) |
| 6 | Φ50X90(35X12) | 26 | Φ75X140(45X22) | 46 | Φ120X140(45X22) |
| 7 | Φ50X90(2P) | 27 | Φ80X110(35X12) | 47 | Φ120X160(70X3P) |
| 8 | Φ55X90(35X12) | 28 | Φ80X110(10) | 48 | Φ130X160(70X3P) |
| 9 | Φ58X90(35X12) | 29 | Φ80X110(4P) | 49 | Φ140X160(70X3P) |
| 10 | Φ60X90(35X12) | 30 | Φ80X110(45X15) | 50 | Φ150X160(70X3P) |
| 11 | Φ60X90(2P) | 31 | Φ80X140(45X22) | 51 | Φ170X170(80X3P) |
| 12 | Φ60X90(2P) | 32 | Φ85X110(45X15) | 52 | Φ200X170(80X3P) |
| 13 | Φ60X110(2P) | 33 | Φ85X140(45X22) | ||
| 14 | Φ60X110(35X12) | 34 | Φ90X110(35X12) | ||
| 15 | Φ65X90(35X12) | 35 | Φ90X110(10) | ||
| 16 | Φ65X90(2P) | 36 | Φ90X110(4P) | ||
| 17 | Φ70X90(35X12) | 37 | Φ90X110(45X15) | ||
| 18 | Φ70X90(2P) | 38 | Φ90X140(45X22) | ||
| 19 | Φ70X90(10) | 39 | Φ95X140(45X22) | ||
| 20 | Φ70X110(35X12) | 40 | Φ100X110(35X12) |
| Length | applicable machines (ton) |
|---|---|
| 70mm | 125 ~ 350t |
| 80mm | |
| 90mm | |
| 110mm | 350t ~ 500t |
| 140mm | 800t ~ 3600t |
| 160mm | |
| 170mm |
